Good price online

products details

Home > Products >
Etched Stainless Steel Sheet
>
Pvd Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness
All Category

Elevator Stainless Steel Sheet

Water Ripple Stainless Steel Sheet

Etched Stainless Steel Sheet

Cold Rolled Stainless Steel Plate

Stainless Steel Tile Trim

Embossed Stainless Steel Sheet

Hairline Stainless Steel Sheet

Stainless Steel Metal Fabrication

Decorative Stainless Steel Sheet

Coloured Stainless Steel Sheet

Stainless Steel Room Divider
  • name
  • name
  • name
  • name
  • name

Pvd Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness

Brand Name: MBT
Model Number: 304
MOQ: 1 PCS
Price: 30-40 USD
Packaging Details: Wooden Case
Payment Terms: L/C,D/A,D/P,T/T
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
ISO, AISI, ASTM, GB, EN, DIN, JIS
Type:
Etched Stainless Steel Sheet
Standard:
ASTM, AISI, GB, JIS, DIN, EN
Shape:
Sheet、Plate
Surface Treatment:
Mirror/Etched
PVC Film:
NORMAL 7C PVC FILM
Thickness:
1.0mm
Size:
1219x2438mm
Grade:
304 Stainless Steel
Supply Ability:
7000-8000 tons/month
Highlight:

Color Coating Etched Stainless Steel Sheet

,

Etched Stainless Steel Sheet 1.0mm Thickness

Product Description
PVD Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness
Hot Sell PVD Color Coating Mirror Etched Stainless Steel Sheet Decoration Sheet
Product Specifications
Type Stainless Steel Etched Sheet
Thickness 0.3 mm - 3.0 mm
Size 1000*2000mm, 1219*2438mm, 1219*3048mm, customized Max. width 1500mm
Grade 201, 304, 304L, 316, 316L, 430 etc.
Available Finishes No.4, Hairline, Mirror, Etched, PVD Color, Embossed, Vibration, Sandblast, Combination, lamination etc.
Available Color Gold, Rose gold, Champagne gold, Copper, Bronze, Black, Blue, Purple, Green etc.
Origin POSCO, JISCO, TISCO, LISCO, BAOSTEEL etc.
Packing Way PVC + waterproof paper + strong sea-worthy wooden package
Chemical Composition
Grade STS 304 STS 316 STS 430 STS 201
Elong(10%) Above 40 30MIN Above 22 50-60
Hardness ≤200HV ≤200HV Below 200 HRB100,HV230
Cr(%) 18-20 16-18 16-18 16-18
Ni(%) 8-10 10-14 ≤0.60% 0.5-1.5
C(%) ≤0.08 ≤0.07 ≤0.12% ≤0.15
Pvd Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness 0
Additional Product Information
Surface: Etched
Grade: 201, 304, 316L, 430 etc.
Materials: Stainless steel sheet/plate
Thickness: 0.3-3.0 mm
Standard Size: 4*8FT
Width: 1000/1219mm/1500mm & customized
Length: Max 4000mm & customized
Remarks:
  • Feel free to contact us for more designs
  • Your own door panel design is welcomed
  • Special dimensions are accepted on request
  • Customized specific cut-to-length, laser-cut, bending are acceptable
Pvd Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness 1 Pvd Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness 2
Stainless Steel Etching Principle
The process uses ferric chloride strong oxidation to corrode the stainless steel surface, converting trivalent iron into more stable bivalent iron elements. The specific production process involves: first coating the stainless steel surface with an anti-corrosion layer to protect required areas, then placing it into the spraying iron trichloride assembly line. After corrosion is complete, the anti-corrosion layer is washed off, forming the desired patterns.
Pvd Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness 3 Pvd Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness 4
Product Packaging
Protective Film
  • Double layer or single layer
  • Normal 7C PVC film, Laser film
Packing Details
  • Wrap with waterproof paper
  • Fasten the straps aligned with edge protection
  • Attach a goods information label to the wooden packing to facilitate easy identification
Packing Case
Strong wooden case, metal pallet and customized pallet are acceptable.
Pvd Color Coating Mirror Etched Stainless Steel Sheet 1.0mm Thickness 5
Frequently Asked Questions
WHERE IS MEIBAOTAI LOCATED?
Our company is located in FOSHAN GUANGDONG CHINA.
Factory Address: A2-3 Factory Building, Sanshan Huadao North Road, Nanhai District, Foshan City, Guangdong Province, China
Export Office Address: Room 1919, Floor 19, Vienna building, Chencun, Shunde, Foshan, Guangdong, China
WHICH REGIONS AND COUNTRIES DO YOU MAINLY EXPORT TO?
We have exported to over 30 countries, mainly in Middle East, Asia, Europe.
COULD WE PUT OUR LOGO ON THE PRODUCTS?
Yes. You can provide us with your logo format and details, and we will apply it to the products for you.
HOW DOES YOUR COMPANY DO REGARDING QUALITY CONTROL?
We continuously track feedback from our clients about our products, which distinguishes us from other suppliers. We are a customer care enterprise.
COULD WE GET A SAMPLE BEFORE A FORMAL ORDER?
Yes, we can provide a sample before order. Checking a sample is the best way to understand the detailed quality.
WHAT'S THE PAYMENT TERM?
When we quote for you, we will confirm the transaction method (FOB, CIF, CNF, etc.). For mass production goods, you need to pay 30% deposit before production and 70% balance against copy of documents. The common way is by T/T. L/C is also acceptable.
